@@ -20,6 +20,25 @@ Even though this player plugin can loop files, it is not an audio looper. |
|
|
|
Audio can loop back to the beginning if enabled, but it does not resample or pitch-shift to fit the host BPM. |
|
|
|
The audio files are played back as-is, with resampling only done when needed to match the host sample rate. |
|
|
|
|
|
|
|
### Audio To CV Pitch |
|
|
|
|
|
|
|
 |
|
|
|
|
|
|
|
The Audio To CV Pitch module is a tool that turns your audio signal into CV pitch and CV gate signals. |
|
|
|
This allows audio from instruments (such as guitars) to play and control synth sounds and effects. |
|
|
|
|
|
|
|
It detects the pitch in your incoming audio signal and outputs a 1V/Oct CV pitch signal on the "Pitch Out" CV port. |
|
|
|
The "Gate" CV port sends out 10V while a pitch is detected, and resets to 0V when the pitch can no longer be detected. |
|
|
|
|
|
|
|
There is an Octave right-click option that allows you to shift the detected pitch up or down by a maximum of 4 octaves. |
|
|
|
When set to 0, it will output the same pitch as is detected on the input. |
|
|
|
|
|
|
|
Then the "Hold Output Pitch" right-click option sets whether the plugin resets its outputs to 0, or holds the last detected pitch. |
|
|
|
|
|
|
|
The Sensitivity parameter can be increased to detect quieter signals, or decreased to reduce artifacts. |
|
|
|
The Confidence Threshold can be increased to make sure the correct pitch is being output, or decrease it to get a faster response time. |
|
|
|
And finally, the Tolerance parameter influences how quickly you can change pitch, turn it down for a more accurate pitch output, or turn it up to make it easier to jump from one pitch to the next. |
|
|
|
|
|
|
|
### Carla |
|
|
|
|
|
|
|
 |
|
|
|
|
